20 X UNIT SPECIFICATIONS
20 X UNIT FRONT
20 X UNIT FRONT
20 X UNIT FRONT
.JPG/:/cr=t:27.54%25,l:33.74%25,w:38.17%25,h:25.45%25/rs=w:1209,h:605,cg:true,m)
- Voltage: 208v, 230v, 480v, 575v
- Motor: 5 HP premium grade
- AMPs-FLA: 208-230v (13.7-12.6), 460v (6.3), 575v (5)
- Drive: Belt and pulley system with auto-tensioner
- CFM: 8500
- Weight: 440 lbs.
- Dimensions: 67” L x 114” W x 31” H
- Construction: Steel, Aluminum, Bolted, Riveted, Sealed
- Finish: White, two-coat power coat
- Applications: Clean and circulate, whole shop filtration
- Db: 68
- Standard Features:
- Easy, no-tool filter changes
- Balanced/Machined drive assembly parts
- Balanced blower
- Greaseable bearings with easy-access grease fitting located outside unit
- Comes standard with spark arrestors
- Many filter options to suit your needs
- Easy-hang uni-strut mounting options available
